GYXTW 9 / 125 OS2 Fiber Optic Single Mode Cable 4 - 48 Cores For Duct / Aerial

GYXTW 9 / 125 OS2 Fiber Optic Single Mode Cable 4 - 48 Cores For Duct / Aerial
GYXTW 9 / 125 OS2 Fiber Optic Single Mode Cable 4 - 48 Cores For Duct / Aerial

Большие изображения :  GYXTW 9 / 125 OS2 Fiber Optic Single Mode Cable 4 - 48 Cores For Duct / Aerial

Подробная информация о продукте:
Место происхождения: КИТАЙ
Фирменное наименование: OEM/ ODM/ YUEXIANKE
Сертификация: UL/ CE/ ETL/ ROHS/ ANATEL
Номер модели: GYTW
Оплата и доставка Условия:
Количество мин заказа: 1000 метров
Цена: Negotiation
Упаковывая детали: 1000 метров
Время доставки: день 3-7Work
Условия оплаты: L/C, D/A, D/P, T/T, западное соединение, MoneyGram
Поставка способности: 100000 метров/день

GYXTW 9 / 125 OS2 Fiber Optic Single Mode Cable 4 - 48 Cores For Duct / Aerial

описание
Модель никакая: ГИСТВ Усильте член:: Металлический
Материал крышки:: PE Использование:: Воздушный
Свободная трубка:: Кабель Uni-трубки Лента воды черня:: УТВЕРДИТЕЛЬНЫЙ ОТВЕТ
Тип:: Однорежимный Отсчет волокна:: 2-144 ядри

GYXTW 9 / 125 OS2 Fiber Optic Single Mode Cable 2 - 48 Cores For Duct / Aerial



Product Description

  • GYXTW is an outdoor use optical fiber cable suitable for duct and aerial applications.
  • We supply GYXTW fiber optic cable from 2 fiber cores to 24 fiber cores.
  • Both single mode type and multimode types are available.
  • Fiber optic cable GYXTW, 2~12 fibers, jelly filled and fiber contained central loose tube, copolymer coated steel tape, two parallel steel wires 1.2mm, PE outer sheath, G652D SM fiber, detailed specification on your request.

Specification



Recommended laying methods Aerial
Allpicable fields Long distance communication and LAN
Properties Water proofing layer providing strong water resistance peformance
Steel tape with PE outer enhancing anti-crush and tensile property of cable
Structure characters Water proofing layer between the steel tape and cable core
Double coated PE corrugated steel tape under PE sheath
Parallel double steel wires as strengthen member

We can design oval cross section and non-metallic structure on

requirement,e.g:GYXTEW,GYFXTW,GYFXTEW etc.



Technicial Data



Fiber range   Cable weight (kg/km) Min.bending radius(mm) Allowable tension(N) Max.crus loading force(N/1000mm)
Cableouter diameter static dynamic short term long term short term long term
2-12 8.9 90 10times cable diameter 20times cable diameter 1500 600 1000 300
12-24 10.2 110



Features



  • Low dispersion and attenuation
  • Proper design, precise control for fiber excess length and distinct stranding process render the cable excellent mechanical and environmental properties
  • Double-jacket structure make cable have nice properties of moisture resistance and crush resistance
  • With small cable diameter, light cable weight, easily to layOperating Temperature: -40 ~ +60 °C



GYXTW 9 / 125 OS2 Fiber Optic Single Mode Cable 4 - 48 Cores For Duct / Aerial 0GYXTW 9 / 125 OS2 Fiber Optic Single Mode Cable 4 - 48 Cores For Duct / Aerial 1GYXTW 9 / 125 OS2 Fiber Optic Single Mode Cable 4 - 48 Cores For Duct / Aerial 2

FAQ



1.What is your MOQ?

Could be coordinated if you have detail requirements.



2.How about your delivery date?
Delivery date is about 3-5days, it depends on the order quantity.

3.Can you supply sample for customers?
Of course, however the delivery cost will be charged on customer's account.

4.How about your price?
We are supplying products with very competitive price based on good performance.

5.Do you offer OEM Service?
We accept OEM, ODM. The cable size and material are customized. Our own logo and own design are welcome. We will produce according to your requirment and description.
